PPA makes it easy to install Hauppauge TV tuners with Ubuntu. PPA's are the only way to get Hauppauge drivers updated in Ubuntu between distro releases. Hauppauge's engineering team has developed the PPA for our TV tuners.

Hauppauge's PPA has support for the following models of Hauppauge TV tuners

• WinTV-HVR-955Q, WinTV-HVR-935C and WinTV-HVR-975 (including analog TV)
• WinTV-dualHD (all models, both tuners)
• WinTV-quadHD (all models)
• WinTV-soloHD (DVB T/T2/C)
• WinTV-HVR-1255 and WinTV-HVR-1265 (including analog TV)
• ImpactVCBe video capture (PCIe)
• USB-Live2 video capture (USB)
• Starburst 2 satellite TV receiver
• PCTV 292e triple mode TV receiver
• PCTV 461e Satellite TV receiver (both old and new models)
• WinTV-NOVA-S2 Satellite TV receiver

PPA supported Linux versions

The Hauppauge PPA supports Ubuntu versions (on Ubuntu desktop and server with 64-bit Intel and AMD processors):

• 14.04 Trusty
• 16.04 Xenial with kernel 4.4
• 16.04.x Xenial HWE
• 18.04 Bionic with kernel 4.15
• 18.04.x Bionic HWE
• 19.04 Disco
• 19.10 Eoan

Hampshire tsharc driver for mac May 24, 2018 by admin If you have a driver or diagnostic tool that sends these requests you can always use a USB trace utility, such as USBlyzer, to trace the requests as they are issued and then replicate the request in the macro wizard. Products sold with the Microchip® or TSHARC™ trademark and does not use any third party technical resources to develop any of its software, device drivers or hardware products. Drivers are available for Windows™ 9x, 2K, ME, XP, XPe, NT™, DOS™, CE™, CE Net, Linux™, MAC and other operating systems and their variations.

For other versions of Linux, you can install the Hauppauge drivers directly.
See this page for instructions.

PPA installation instructions for TV tuner driver on Ubuntu

Open Terminal in Ubuntu The easiest way to open terminal is to right click on desktop and select Open Terminal. You can also click Ctrl+Alt+T on your keyboard.

In Terminal, type the following or copy and paste the following lines, one by one, then click enter.

sudo add-apt-repository ppa:b-rad/kernel+mediatree+hauppauge

After this first line, click enter when prompted to add this PPA.

sudo apt-get update

sudo apt-get install linux-mediatree

Note: if you are using a Hauppauge DVB TV tuner in Europe or Australia/New Zealand, you also need to install the TV firmware:

sudo apt-get install linux-firmware-hauppauge

Close Terminal and restart your computer.

You can now connect your Hauppauge WinTV TV tuner to your computer and it should be available for use by your Linux TV watching application.

Notes:

GIT

If you'd like to see the latest directions from the GIT repository, click here

Still having problems?

If you install the package, but still lack driver support, you may be running an Ubuntu HWE kernel. To determine enter this command in terminal:
dpkg -l grep linux-image-generic-hwe
If a line is displayed beginning with 'ii', then the installation command is different:
sudo apt-get install linux-hwe-mediatree

This support is for Plex running under Ubuntu

Our PPA supports the following Ubuntu versions:

• 16.04 Xenial with kernel 4.4
• 17.10 Artful with kernel 4.13
• 18.04 Bionic with kernel 4.15

Xenial available here http://old-releases.ubuntu.com/releases/16.04.1/.

We do not currently support LTS Enablement Stacks under Ubuntu Linux 16.04.2 Xenial. For more information about LTS Enablement Stack please visit this page https://wiki.ubuntu.com/Kernel/LTSEnablementStack

nVidia Shield and Plex with the Hauppauge WinTV-dualHD

You can use the Hauppauge WinTV-dualHD (North America, Europe, Australia and New Zealand) on the nVidia Shield for live TV in Plex. You will need the latest version of nVidia Shield firmware (5.2 or later).

Setting up Plex TV with a Hauppauge TV tuner on the NVidia Shield

Here are some ideas on cord cutting from the nVidia blog.

The Hauppauge PPA

Hauppauge has created a PPA to simplify adding TV tuner drivers into Linux. Using the Hauppauge PPA will allow easier installation of Plex with Hauppauge TV tuners. The current Hauppauge PPA has support for the following tuners:

• WinTV-HVR-955Q for North America: single tuner
• WinTV-soloHD for Europe/Australia/New Zealand: single tuner
• WinTV-dualHD for North America, Europe and Australia/New Zealand: dual tuner
• WinTV-quadHD for North America, Europe and Australia/New Zealand: quad tuner

PPA installation

Open Terminal in Ubuntu The easiest way to open terminal is to right click on desktop and select Open Terminal. You can also click Ctrl+Alt+T on your keyboard.

In Terminal, type the following or copy and paste the following lines, one by one, then click enter.

sudo add-apt-repository ppa:b-rad/kernel+mediatree+hauppauge

After this first line, click enter when prompted to add this PPA.

sudo apt-get update

sudo apt-get install linux-image-mediatree

sudo apt-get install linux-headers-mediatree

Close terminal and restart your computer.

You can now connect your Hauppauge WinTV-dualHD TV tuner to your computer and it should be available for Plex.

Note: After you install Plex please run the following command in terminal to provide the appropriate tuner permission to Plex
sudo usermod -a -G video plex

Note: If you'd like to see the latest directions from the GIT repository, click here

nVidia Shield and Plex with the Hauppauge WinTV-dualHD

You can use the Hauppauge WinTV-dualHD on the nVidia Shield for live TV in Plex. You will need the latest version of nVidia Shield firmware (5.2 or later).

Here are some ideas on cord cutting from the nVidia blog.

Questions?

If you have any questions, you can contact Hauppauge support at: techsupport@hauppauge.com

Hauppauge technical support tested various Hauppauge TV tuners with Ubuntu Desktop, and has created both a video and a list of steps to install the TV tuners on Ubuntu Desktop 14.04.2. If you have any questions, you can contact Hauppauge support at: techsupport@hauppauge.com

Ubuntu installation video

Ubuntu installation instructions

Linux drivers for Hauppauge TV tuners

Kernel 3.16 This Linux driver package is for the WinTV-HVR-955Q, the WinTV-HVR-1955 and HVR-1975, plus all versions of the WinTV-HVR-2255 and HVR-2205 on Ubuntu Desktop 14.04.2 with kernel 3.16

Kernel 3.19 Updated kernel patch for 3.19 on Ubuntu Desktop 14.04.3

Kernel 4.2 Ubuntu Desktop 14.04.4 includes kernel 4.2 with built in support for the WinTV-HVR-955Q and the WinTV-HVR-2255. So there is no need to compile your own kernel.

Kernel 4.4 or later Our PPA includes support for many Hauppauge TV tuners for kernel 4.4 or later. Please see our PPA page.

Firmware install instructions for the WinTV-HVR-2200

Note: The WinTV-HVR-2255 will require a firmware file. Please go to LinuxTV.org for information or contact Hauppauge support: techsupport@hauppauge.com

cd /tmp
wget http://hauppauge.com/linux/firmware_2200.fw
md5sum firmware_2200.fw # verify first couple and last couple chars
sudo cp firmware_2200.fw /lib/firmware

Hauppauge technical support has been testing with the Raspberry Pi 3 and 4, which work 'out of the box' with Raspbian OS 4.19 or later with these Hauppauge TV tuners: WinTV-dualHD (North America and Europe), WinTV-HVR-955Q, 461e/WinTV-Nova-S2.

Raspian OS

The WinTV-dualHD drivers come with the latest Raspbian OS, so all you need to do is plug your WinTV-dualHD into your RPi 3 or 4, install a TV application like Kaffeine, connect an antenna and scan for channels.

Firmware needed for some Hauppauge TV tuners

Some Hauppauge TV tuners need additional firmware to be install on your Raspberry Pi. Here are the command lines to add Hauppauge firmware for those tuners which need it. You can load the firmware at any time, but it needs to be installed before you use the TV tuner.

Firmware install instructions for the WinTV-dualHD and WinTV-soloHD for Europe:

cd /tmp
wget http://www.hauppauge.com/linux/dvb-demod-si2168-b40-01.fw
md5sum dvb-demod-si2168-b40-01.fw # verify first couple and last couple chars
sudo cp dvb-demod-si2168-b40-01.fw /lib/firmware

Firmware install instructions for the 461e or WinTV-Nova-S2:

cd /tmp
wget http://www.hauppauge.com/linux/dvb-fe-ds3103.fw
md5sum dvb-fe-ds3103.fw # verify first couple and last couple chars
sudo cp dvb-fe-ds3103.fw /lib/firmware

Firmware install instructions for the WinTV-HVR-1950

cd /tmp
wget http://www.hauppauge.com/linux/firmware_1900.fw
md5sum firmware_1900.fw # verify first couple and last couple chars
sudo cp firmware_1900.fw /lib/firmware

Satellite TV for your Raspberry Pi

Use the PCTV 461e Satellite TV receiver with your Raspberry Pi. Here is a video on how to install the drivers and how to use the 461e with Kaffeine to watch satellite TV.

www.youtube.com/watch?v=dsRn9CLXCJo

The current version of OpenELEC 6.0.1 Kernel also has support out of the box for the WinTV-dualHD (both North America and European versions) plus the WinTV-HVR-955Q. All Hauppauge drivers and firmware are included as part of the OpenElec distribution, so you don't need to add the firmwer. Just plug your Hauppauge TV tuner into a USB port and fire up OpenElec.

OpenElec also includes Kodi, which you can use as your TV viewer.

OpenELEC can be downloaded from http://openelec.tv/get-openelec

Please check the OpenELEC community on how to install and run an operating system on the Raspberry Pi.

All you need to do is connect the HVR-955Q to a USB port on the Raspberry Pi.

The firmware is already included nothing else needs to be done to get the HVR-955Q detected.

Ubuntu installation video

Click here for our Ubuntu installation video

Ubuntu installation instructions for the HD PVR 2

Note: Please check on the bottom of your HD PVR 2 for the 6 digit 157xxx model number. Download the correct package for your model below.

We have tested with Live Channels version 1.14.012

Supported Hauppauge TV tuners include the WinTV-HVR-955Q and the WinTV-dualHD for North America. At this time, there are no DVB TV tuners supported in Live Channels.

Here is an installation video for Live Channels

Note: if you are getting TV video but no audio with Live Channels, most likely your video monitor is missing an AC3 decoder. With Live Channels, you need to have a video monitor connected to your Android system which has an AC3 decoder built in. Unlike Plex (which decodes AC3 and turns it into two channel audio if needed), Live Channels does not decode the AC3. If you are using a video monitor which does not support AC3 surround sound audio, you can use a sound bar (which normally have AC3 decoders built in).

Download And Listen Online Bollywood Hindi Movie Yaarana (1981): MP3 Songs Free. Download All Songs Of Hindi Movie Yaarana (1981): MP3 Songs And Listen Totally Free Online In HD Quality, 128 Kbps, 320 Kbps. SongsMP3 and Gaana Of Bollywood Hindi Movie Also With Fast Direct Download Links. Listen Online And Download Only On DownloadMing. Yaarana Free Mp3 Download Yaarana Song Free Download Yaarana Hindi Movie Mp3 Download Yaarana Video Download Yaarana Free Music Download Sara Zamana Kishore Kumar/100064,Chukar Mere Mann Ko Kishore Kumar/100064,Kishan Chacha Mohammed Rafi/100055,Bole Bole Kishore Kumar/100064,Tu Rootha Kishore Kumar/100064,Tere Jaisa Yaar Kahan Kishore Kumar/100064, Yaarana 1981 Hindi Movie Mp3 Song Free Download. Mohammad Rafi Old Hindi Songs -Mohd Rafi Old Instrumentals Songs Old Singers Old Super Stars Songs Collection Popular Songs A to Z Romantic - Old Hindi Songs Sad Songs Mukesh Kumar Old Songs Manna Dey -Songs R D Burman Songs Rahat Fateh Ali Khan Songs. Yaarana chhu kar mere man ko. Description: Yarana (1981) Bollywood Movie Mp3 songs In 128Kbps, 190Kbps, 320Kbps Quality Format, Yarana (1981) Movie Original Soundtrack Yarana (1981) Mp3 Songs Download Itunesrip, Yarana (1981) Bollywood Movie Mp3 Songs, Yarana (1981) Movie Original Cdrip Full Album, Yarana (1981) Bollywood Hindi Film All Song Download, Yarana (1981) All Mp3 Songs Download.

Linux support for Colossus 2 is through a user mode application. You can get the application from the link below.

Ubuntu installation video (for Colossus 2 and HD PVR 2)

Ubuntu installation instructions for the Colossus 2 and HD PVR 2

Download the Linux Colossus 2 application:

MythTV and the Colossus 2

John Poet has created Colossus 2 support for MythTV, including AC3 audio support:

https://github.com/jpoet/HauppaugeUSB/network

Pal from Snap.TV has forked the MythTV Colossus 2 support and has added support for analog PAL composite video.

Use Kaffeine to watch live TV on your Linux system with a Hauppauge WinTV TV tuner
